Гидравлическая соединительная муфта типа S, HCS70, 678-7478

Couplings are machined and sized for the high-flow performance required by hydromechanical attachments. Better hydraulic flow results in fuel efficiency gains from reduced back pressure. Enclosed spring prevents contamination of hydraulic system. Durable and reliable fluid connections create a system for hydraulic fluid flow and no opportunity for spills during tool exchange. Internally routed hoses in the bracket and coupler use fewer external hoses, reducing overall hose and repair costs.

Гидравлическая соединительная муфта типа S, HCS70, 678-7478. Назначение: подключение и быстрая смена совместимого навесного оборудования. Конкретный режим применения определяется комплектацией базовой машины и установленным рабочим оборудованием.

Changing attachments with hydraulic connecting couplers is 98% faster than pin-on. Using hydraulic connect couplers instead of mechanical couplers saves 96% time in changing attachments. Quick disconnect design improves lifespan and is easy to service. Design of cover lid and sealing adds protection for couplings and prevents contamination to hydraulic system. Machined position of the quick disconnect valves on the tool and on the bracket ensure a tight and reliable connection limiting chance of leaks or damage. Quick disconnect couplings are installed in the same direction as the locking force with a solid flange to ensure a solid fit. No locking rings or nuts which increase the chances of loose or broken parts.

Конструктивное исполнение рассчитано на рабочие нагрузки, возникающие при штатной эксплуатации. Для сохранения ресурса необходимо соблюдать допустимые нагрузки и регламент обслуживания.

Industry-leading safety features in sensor technology. Safe coupler locking complies with updated European EN474 safety standard. Keep everyone on the job site safer. The operator stays safe in the cab and no assistance is required to connect or disconnect hydraulic hoses during attachment changes. Multiple electronic and mechanical measures in place to keep attachment secure, even if a pressure loss occurs. Operator has visual and audible confirmations from inside the cab of successful attachment connection. Heavy-duty locking wedge design keeps connections tight and in place during use.

Согласование геометрии, крепления и рабочих параметров с базовой машиной помогает использовать доступную мощность без лишних потерь и сокращать время выполнения операций.

Компоновка рассчитана на понятное подключение и эксплуатацию в составе совместимой техники. Перед началом работы проверяются фиксация, соединения и отсутствие помех движению оборудования.

Attachment switching with a hydraulic connect coupler: Quick changes mean operators will utilize task and application appropriate attachments, increasing overall productivity and extending the life of the attachments. The ability to exchange attachments easily can reduce the number of machines needed for a job. Fast attachment changes with the hydraulic connecting interface will save time over static couplers or pin-on attachments. Electric connector allows for full functionality when working in combination with tiltrotators, ditch cleaning tilt buckets, and mulchers or other attachments with electronic harnesses for grade sensors or tool functions. Each coupler comes standard with a lifting hook with 5-, 8- or 10-ton lift capacity depending on the size class.

The Cat® PL161 attachment locator keeps track of attachments across every jobsite with Bluetooth enabled location visibility. Monitor attachment utilization by capturing real working hours for smarter maintenance planning. View machines and attachments together in VisionLink™ for full fleet visibility and management. Rugged, maintenance-free design with up to two years of battery life.

Периодический осмотр креплений, рабочих поверхностей, шлангов и соединений помогает своевременно выявлять износ и предотвращать внеплановые остановки техники.
